The visual pathway is the neural circuit that carries visual information from the photoreceptors in the retina to the primary visual cortex in the occipital lobe. Understanding this pathway is essential for interpreting visual field defects — different lesion locations produce characteristic, predictable patterns of vision loss that provide clues about the underlying cause.
For the CPO and CPOA exams, the key concept is understanding what happens at the optic chiasm (where fibers partially cross), why post-chiasmal lesions cause bilateral visual field defects affecting the same side in both eyes (homonymous hemianopia), and what clinical conditions are associated with each pattern of field loss.
This knowledge directly supports your role in performing visual field tests, documenting findings accurately, and understanding when a visual field result requires urgent clinical attention.
1. Retina
Photoreceptors (rods and cones) convert light to electrical signals. Retinal ganglion cell axons form the optic nerve. Nasal retina sees temporal visual field; temporal retina sees nasal visual field.
2. Optic Nerve (CN II)
Intraocular portion exits at optic disc. Retrobulbar portion travels through the orbit. Intracanalicular portion passes through optic canal. Intracranial portion reaches the chiasm. Lesion here causes monocular vision loss.
3. Optic Chiasm
Partial decussation: nasal fibers (temporal field) cross; temporal fibers (nasal field) stay ipsilateral. Located above pituitary gland. Lesion causes bitemporal hemianopia (pituitary adenoma is most common cause).
4. Optic Tract
Post-chiasmal. Contains crossed nasal fibers from opposite eye + uncrossed temporal fibers from same eye — both representing the contralateral visual field. Lesion causes contralateral homonymous hemianopia.
5. Lateral Geniculate Nucleus (LGN)
Thalamic relay station. Retinotopically organized (maintains spatial map of visual field). Projects to primary visual cortex via optic radiations. Lesion causes contralateral homonymous hemianopia.
6. Optic Radiations (Geniculocalcarine Tract)
Fan out through temporal and parietal lobes. Meyer's loop (inferior fibers through temporal lobe) carries superior visual field. Lesion of Meyer's loop: superior quadrantanopia ("pie in the sky"). Parietal lesion: inferior quadrantanopia.
7. Primary Visual Cortex (V1 / Striate Cortex)
In the calcarine fissure of the occipital lobe. Macula represented at the posterior pole (large area). Stroke here: contralateral homonymous hemianopia, often with macular sparing (dual blood supply of macula).
Complete vision loss in one eye only. Caused by retinal disease (CRAO, detachment), optic neuritis, ischemic optic neuropathy, or optic nerve compression. The fellow eye has normal visual field. Afferent pupillary defect (APD) present with significant optic nerve disease.
Loss of both temporal (outer) visual fields. Classic for chiasmal lesion, most often pituitary adenoma. Patient may report difficulty seeing at the outer edges. May be asymmetric early. Pituitary tumors can also cause hormonal symptoms (acromegaly, Cushing's, hyperprolactinemia) and headache.
Loss of the same half of the visual field in both eyes (right-sided or left-sided). LEFT hemisphere lesion → RIGHT homonymous hemianopia. RIGHT hemisphere lesion → LEFT homonymous hemianopia. Caused by stroke, tumor, or trauma. Common cause of driving-related accidents. Patient may be unaware unless specifically tested.
Loss of one quadrant. Superior quadrantanopia ("pie in the sky") = Meyer's loop lesion in temporal lobe (often temporal lobe epilepsy surgery). Inferior quadrantanopia ("pie on the floor") = parietal lobe lesion. Quadrantanopias are contralateral and homonymous (same quadrant lost in both eyes).
Inflammation of the optic nerve, often demyelinating (MS). Monocular vision loss, pain with eye movement, APD. Typically recovers. First presentation may trigger MS workup.
Most common cause of bitemporal hemianopia. May present with hormonal symptoms. Visual field testing is key in monitoring. Treated surgically or medically depending on type.
Most common cause of homonymous hemianopia. PCA supplies occipital cortex. Often with macular sparing. May be unaware of deficit. Vision rarely fully recovers.
Damage to optic nerve fibers. Produces arcuate scotomas and nasal steps — not a hemianopia pattern. Bilateral but usually asymmetric. Testing with 24-2 HFA is standard.
New Homonymous Defect = Neurological Emergency
A patient presenting with sudden onset of homonymous visual field loss, especially with headache, facial droop, limb weakness, or speech difficulty, may be having an acute stroke. Call 911. Stroke treatment is highly time-sensitive (tPA within 3-4.5 hours). Do not delay by performing a full eye exam — get emergency services activated immediately while alerting the doctor.
Complete overview of ocular structures including posterior segment.
Measuring and recording VA, pinhole testing, and chart types.
Gross field screening technique and common defect patterns.
All CPO and CPOA study topics organized by category.
The optic chiasm is the X-shaped structure where the two optic nerves meet at the base of the brain, just anterior to the pituitary gland. Here, a partial decussation occurs: nerve fibers from the nasal half of each retina (carrying temporal visual field information) cross to the opposite side, while fibers from the temporal half of each retina (carrying nasal visual field information) stay ipsilateral. After the chiasm, each optic tract contains fibers from both eyes representing the contralateral visual field. A lesion at the chiasm — most commonly a pituitary adenoma pressing from below — damages the crossing nasal fibers preferentially, producing bitemporal hemianopia: loss of both temporal (outer) visual fields. This is sometimes called "tunnel vision" but true tunnel vision (concentric constriction) is different. Bitemporal hemianopia is pathognomonic for a chiasmal lesion.
A homonymous hemianopia is loss of the same half of the visual field in both eyes — for example, both right halves (right homonymous hemianopia) or both left halves (left homonymous hemianopia). It is caused by a lesion anywhere along the visual pathway posterior to the optic chiasm: the optic tract, lateral geniculate nucleus, optic radiations, or visual cortex. The most common cause is stroke (ischemic or hemorrhagic) in the posterior cerebral artery territory (supplies the occipital cortex) or middle cerebral artery territory (supplies optic radiations). Tumors, trauma, and hemorrhage are other causes. Right homonymous hemianopia is caused by a lesion of the LEFT optic tract/radiation/cortex. This is because of the crossing that occurs at the chiasm — the left hemisphere processes the right visual field.
A pituitary adenoma (the most common cause of chiasmal compression) classically causes a bitemporal hemianopia — loss of both outer (temporal) visual fields. The pituitary gland sits in the sella turcica directly below the optic chiasm, so as the tumor grows superiorly, it compresses the crossing nasal retinal fibers at the chiasm. These nasal fibers carry temporal visual field information, explaining why temporal fields are lost. Early presentation may be an asymmetric bitemporal defect or a superior temporal quadrantanopia. The visual field defect is often the first symptom of a pituitary adenoma — it may occur before headache or hormonal symptoms. Some patients notice they have stopped reading text at the outer edges of pages or have had peripheral traffic accidents. Automated visual field testing is essential in evaluating suspected chiasmal pathology.
Macular sparing refers to preservation of central (macular) vision despite a homonymous hemianopia from an occipital cortex lesion. It occurs because the macula has dual blood supply — both the posterior cerebral artery (PCA) and middle cerebral artery (MCA) contribute to the occipital pole where central vision is represented. If a PCA stroke spares the occipital pole (supplied by MCA collaterals), the patient loses peripheral visual field but retains central vision. This is clinically significant because patients with macular sparing can still read and have some functional vision despite the hemianopia. They may not even notice the defect initially. Macular sparing is most common with large cortical infarcts; smaller, more posterior lesions tend not to spare the macula.
A new visual field defect — particularly one that is bilateral, homonymous, or associated with other neurological symptoms — requires urgent physician evaluation and often neuroimaging. The paraoptometric should: document the defect precisely (which field(s), how severe, when it started), ask about associated symptoms (headache, confusion, weakness, speech difficulty, diplopia), and alert the doctor immediately without dismissing the finding as an artifact or instrumentation problem. Do not attempt to repeat the field multiple times hoping for a better result — if the defect is confirmed on two attempts with adequate reliability indices, it is real. For a patient who describes sudden loss of part of their vision with headache, nausea, or other neurological symptoms and is presenting to the office, call 911 — this may be an acute stroke requiring emergent intervention within the treatment window.
